Product Details:

Place of Origin: Guangdong, China
Brand Name: EliteLED, OEM
Certification: CE, ROHS
Model Number: P4 P5 P8 P10

Payment & Shipping Terms:

Minimum Order Quantity: 1 Pieces
Price: Negotiable
Packaging Details: Wooden cases or flight cases
Delivery Time: 15 days
Supply Ability: 3000sqm/month
Get Best Price Contact Now

Detail Information

Application: Stage Event, Advertising Pixel Pitch: 4-10mm
Brightness: 7000nits Product Name: P4 Outdoor Led Screen
Cabinet Size: 960x960mm Module Size: 320x160mm
LED Chip: Nationstar Kinglight Certificate: CE ROHS
Warranty: 3 Years Port: Shenzhen
High Light:

960x960mm P4 Outdoor Led Display Large

,

960x960mm Large Led Advertising Screens

,

7000nits P4 outdoor led display

Product Description

960x960mm Cabinet P10 P8 P5 P4 Outdoor Rental Led Display Screen Large Advertising Board



Our Advantages:



1. Providing excellent customer service and technical support.


2. We have very strict quality control system for every production procedure.


3. We introduced advanced technology equipment, we can delivery products on time, no matter samples or customized products.


4. We have experienced technology enginners team and sales team to answer and solve all your concerned matters.


5. Our products passed CE, FCC and RoHS certificates.


6. The best price. You are welcome to contact us for a free project evaluation.



Model

P4

P5

P6

P8

P10

Pixel Pitch(mm)

4

5

5.7

8

10

LED Chips

SMD1921

SMD2727

 SMD2727

 SMD3535

 SMD3535

Pixel density(dots/m2)

62500

40000

30625

15625

10000

Driving Method

1/10 scanning

1/8 scanning

1/7 scanning

1/5 scanning

1/2 scanning

Module Size(mm)

320*160

320*160

320*160

320*160

320*160

Module Resolution

80*40

64*32

56*28

40*20

32*16

Cabinet Size( W*L mm)

960*960

960*960

960*960

960*960

960*960

Cabinet Material

Magnesium

Alloy

Magnesium

Alloy

Magnesium

Alloy

Magnesium

Alloy

Magnesium

Alloy

Cabinet Weight( Kg/m2 )

35

35

35

35

35

Max.Consumption(W/m2)

800

800

800

800

800

Ave.Consumption(W/m2)

350

350

350

350

350

Brightness( Nits )

≥6800

≥6500

≥6500

≥6500

≥6800

Viewing Angle (Vertical / Horizontal)

120° / 120°

120° / 120°

120° / 120°

120° / 120°

120° / 120°

Refresh Rate

≥1920Hz

≥1920Hz

≥1920Hz

≥1920Hz

≥1920Hz

IP Level

IP65

IP65

IP65

IP65

IP65

960x960mm 7000nits P10 P8 P5 P4 Outdoor Led Display Large Led Advertising Screens 0960x960mm 7000nits P10 P8 P5 P4 Outdoor Led Display Large Led Advertising Screens 2



960x960mm 7000nits P10 P8 P5 P4 Outdoor Led Display Large Led Advertising Screens 4



960x960mm 7000nits P10 P8 P5 P4 Outdoor Led Display Large Led Advertising Screens 5



About Us:



EliteLED is a professional manufacturer of LED Video walls ,outdoor indoor LED Display Screen, LED Panel in Shenzhen, China with led display exported to more than 100 countries and regions, passed CE,ROHS FC Certifications, If you are considering LED go with the known leader of LED display suppliers, please contact us.

Our Services

1. Warranty is for 2 years: During the warranty period, we will maintain and replace the defect components for free if there is any quality problem due to us. After 2 years, we will charge the material and freight cost.



2. Free Training: You can send your engineers to our factory for free of charge training, which includes the software, operation, installation, adjustment, basic repairing, etc.



3. Technical Support: All operation manuals, software, CAD drawings of the steel structure and instruction of installing the cabinets can be provided for free. Online technical support by remote control is also available. If needed, we can send engineers to your country to instruct and help the installation.



4. If you need, we can send our engineer to guide the installation for you. But the relevant cost should be paid by your company such hotel, food, round trip ticket.

FAQ

1. What about the warranty?

We have two years warranty, spare parts such as led module, control card, power supply are damaged not caused of artificial damaged, then it's free maintenance and ship back new ones for replacement.



2. How about the quality?

Our led products must be aging at least 48 hours before shipping, from purchasing raw materials to ship, each process has strict quality control systems to ensure led display with good quality.



3. Can you offer a technical support?

We provide free training for our customer, teach the client how to set up screens, make configuration of parameters, broadcast the videos through Novastar and colorlight or Linsn control systems, our engineer can directly teach you how to operate. We're innovative high-end led display with over 10 years manufacturing experience, and we believe you can get a professional solution and best service from us. If any question, you are welcome to contact us! We're happy to serve you.
