ROHS P8mm Outdoor Led Video Screen led ad display panel Cool Low Temperature
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | EliteLED |
| Certification: | CE, CCC |
| Model Number: | P8 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1sqm |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Wooden cases or flight cases |
| Delivery Time: | 18 days |
| Supply Ability: | 3000sqm/month |
|
Detail Information |
|||
| Application: | Outdoor Advertising | Pixel Pitch: | 8mm |
|---|---|---|---|
| Brightness: | 7000nits | Product Name: | P8 Outdoor Led Panel |
| Cabinet Size: | 960x960mm | LED Chip: | Nationstar, Kinglight |
| Control System: | Nova | Certificate: | CE ROHS |
| Warranty: | 2 Years | ||
| High Light: | P8mm Outdoor Led Video Screen,P8mm Led Ad Display Panel,ROHS Outdoor Led Video Screen |
||
Product Description
P8 Outdoor Energy Saving Cool Low Temperature LED Billboard LED Display
Key Specifictions:
1. Steel and aluminum cabinet are options. Accept size customize,can do concave, convex shapes.
2. Front and rear access. Another front open panel cabinet for choose.
3. Inside of module have buckle design for adjusting gaps between module and cabinet,to ensure the connection become tighter and seamless.
4. Lighter sensor be added on the led display to adjust the bright according to enviroment. Extremly guaranteed the longer lifespan and better visual effective for display.
5. Power cable and signal cable can just insert from the hole of beside,saved cost for customers.
6. About control system,we classified synchronous control and asynchronous control.The asynchronous control can make use of USB, RJ45, WIFI and 4G to transmitted.
|
Model |
P4 |
P5 |
P6 |
P8 |
P10 |
|
Pixel Pitch(mm) |
4 |
5 |
6.67 |
8 |
10 |
|
LED Chips |
SMD1921 |
SMD2525 |
SMD3535 |
SMD3535 |
SMD3535 |
|
Pixel density(dots/m2) |
62500 |
40000 |
22477 |
15625 |
10000 |
|
Driving Method |
1/10 scanning |
1/8 scanning |
1/6 scanning |
1/5 scanning |
1/2 scanning |
|
Module Size(mm) |
320*160 |
320*160 |
320*160 |
320*160 |
320*160 |
|
Module Resolution |
80*40 |
64*32 |
48*24 |
40*20 |
32*16 |
|
Cabinet Size( W*L mm) |
960*960 |
960*960 |
960*960 |
960*960 |
960*960 |
|
Cabinet Material |
Magnesium Alloy |
Magnesium Alloy |
Magnesium Alloy |
Magnesium Alloy |
Magnesium Alloy |
|
Cabinet Weight( Kg/m2 ) |
35 |
35 |
35 |
35 |
35 |
|
Max.Consumption(W/m2) |
800 |
800 |
800 |
800 |
800 |
|
Ave.Consumption(W/m2) |
350 |
350 |
350 |
350 |
350 |
|
Brightness( Nits ) |
≥5500 |
≥5000 |
≥5500 |
≥5800 |
≥6000 |
|
Viewing Angle (Vertical / Horizontal) |
120° / 120° |
120° / 120° |
120° / 120° |
120° / 120° |
120° / 120° |
|
Refresh Rate |
≥1920Hz |
≥1920Hz |
≥1920Hz |
≥1920Hz |
≥1920Hz |
|
IP Level |
IP65 |
IP65 |
IP65 |
IP65 |
IP65 |
About Us:
SHENZHEN ELITELED ELECTRONICS CO., LTD. is a leading LED display applications products and solutions provider, specialized in LED research and development, manufacturing. Sales and servic, dedicated to providing high-quality, high-performance LED applications and solutions for professional channel customers and end-users at home and abroad.
Our products have been widely used both at home and abroad. Since its foundation, we have become one of the best LED product and solution providers in the country through our unremitting efforts and have won the industry's highest recognition
The development of the company so far, the sales outlets throughout the country, the export products exported to more than 10 countries and regions, 3C, FCC, CE, IP65, IP67, IS9001, ROHS, and other qualifications, product testing reports, patent certificate.
Our Service:
1. What about the warranty?
We have two years warranty, spare parts such as led module, control card, power supply are damaged not caused of artificial damaged, then it's free maintenance and ship back new ones for replacement.
2. How about the quality?
Our led products must be aging at least 48 hours before shipping, from purchasing raw materials to ship, each process has strict quality control systems to ensure led display with good quality.
3. Can you offer a technical support? Since it's my first time....
We provide free training for our customer, teach the client how to set up screens, make configuration of parameters, broadcast the videos through Novastar and colorlight or Linsn control systems, our engineer can directly teach you how to operate. We're innovative high-end led display with over 10 years manufacturing experience, and we believe you can get a professional solution and best service from us. We're happy to serve you. If any question, you are welcome to contact us!
