Vivid Image SMD1515 P2.97mm Stage Rental LED Screen For Big Concert
|Place of Origin:||Guangdong, China|
Payment & Shipping Terms:
|Minimum Order Quantity:||2 Pieces|
|Packaging Details:||Flight case, 6-8pcs cabinets in one flight case.|
|Delivery Time:||15 days|
|Supply Ability:||3000 Square Meters/Month|
|Application:||Stage Events||Pixel Pitch:||2.97mm|
|LED Encapsulation:||KN-light, Nationstar||Brightness:||1000 Nits|
|Refresh Rate:||3840Hz||Cabinet Size:||500x500mm|
|Product Name:||P2.97 Led Screen||Control System:||Nova|
|Certificate:||CE ROHS FCC|
P2.97mm Stage Rental LED Screen,
SMD1515 Stage Rental LED Screen,
P2.97mm Stage Rental LED display
P2.97mm Nationstar Led Lamp SMD1515 Stage Led Screen Display For Big Concert
Standard 500x500mm, 500x1000mm cabinet size, Silan driving IC, refresh rate reach to 3840HZ. Cabinet adopts curve fast locks, can realize the arc splicing effect of 5-10 degrees of internal radian and 5 degrees of external radian. Stable cabinet structure, no deformation, the contact surface between cabinet is treated by anodic oxidation, which is resistant to collision and friction, satisfying multiple installation and disassembly in rental events.
1. Standard dimension,module size 250mm * 250mm, cabinet size 500mm * 1000mm, compatible indoor P2.604/2.97/3.91 and outdoor P3.91/4.81.
2. High-precision die-cast aluminum cabinet, seamless unit box.
3. New design of hanging bar lock, one hand to fix two cabinets,anti-fool design to avoid loose cabinet caused by unintentional touch.
4. Total hard connection, easy to take off the power supply and receiving card.
5. Module with touchable back screw, uncessary to prepare tool, easy to fix and take off modules by hand.
6. Corners with small protectors, protect pixel while moving.
1. High refresh rate, >3840HZ, which let the picture is vivider
2. All led panels have high strength corner protectors. Protect leds from damage during transportation and installation.
3. Convenient maintainance --- module front & rear service
4. Independent power supply box without wire
5. Support curve connection --- ±2.5°&5° concave & converse connection
|Pixel Density||112,896 pixels/sqm||65,536 pixels/sqm||43,264 pixels/sqm|
|Module Dimension (W*H)(mm)||250*250||250*250||250*250|
|Physical Resolution of Panel(W*H)||168*168/168*336||128*128/128*256||104*104/104*208|
|Panel Material||Die-Casting Aluminum||Die-Casting Aluminum||Die-Casting Aluminum|
|Single Cabinet Weight||8/14 kg/panel||8/14 kg/panel||8/14 kg/panel|
|Processing||16 bit||16 bit||16 bit|
|Average Power Consumption||64/128 W/panel||64/128 W/panel||64/128 W/panel|
|Max Power Consumption||192/384 W/panel||192/384 W/panel||192/384 W/panel|
|Refresh Rate||>1,920 Hz||>1,920 Hz||>1,920 Hz|
|Brightness||>1,200 nits||>1,200 nits||>1,200 nits|
|Horizontal Viewing Angle||160°||160°||160°|
|Vertical Viewing Angle||140°||140°||140°|
