SMD1515 Stage LED Video Wall

SMD1515 Stage LED Video Wall

Product Details:

Place of Origin: Guangdong, China
Brand Name: ELITELED
Certification: CE
Model Number: P2.97

Payment & Shipping Terms:

Minimum Order Quantity: 2 Pieces
Price: Negotiable
Packaging Details: Flight case, 6-8pcs cabinets in one flight case.
Delivery Time: 15 days
Supply Ability: 3000 Square Meters/Month
Get Best Price Contact Now

Detail Information

Application: Stage Events Pixel Pitch: 2.97mm
LED Encapsulation: Nationstar Brightness: 1000 Nits
Refresh Rate: 3840Hz Cabinet Size: 500x500mm
Product Name: P2.97 Led Screen Control System: Nova
Certificate: CE ROHS FCC
High Light:

SMD1515 Stage LED Video Wall

,

SMD1515 led stage display screen

,

Stage LED Video Wall 2.97mm

Product Description

Nationstar Led Lamp SMD1515 Stage Led Video Wall Screen Display For Big Concert



Introduction:



Standard 500x500mm, 500x1000mm cabinet size, Silan driving IC, refresh rate reach to 3840HZ. Cabinet adopts curve fast locks, can realize the arc splicing effect of 5-10 degrees of internal radian and 5 degrees of external radian. Stable cabinet structure, no deformation, the contact surface between cabinet is treated by anodic oxidation, which is resistant to collision and friction, satisfying multiple installation and disassembly in rental events.



1.Standard dimension,module size 250mm * 250mm, cabinet size 500mm * 1000mm, compatible indoor P2.604/2.97/3.91 and outdoor P3.91/4.81.



2.High-precision die-cast aluminum cabinet, seamless unit box.



3.New design of hanging bar lock, one hand to fix two cabinets,anti-fool design to avoid loose cabinet caused by unintentional touch.



4.Total hard connection, easy to take off the power supply and receiving card.



5.Module with touchable back screw, uncessary to prepare tool, easy to fix and take off modules by hand.



6.Corners with small protectors, protect pixel while moving.



SMD1515 Stage LED Video Wall 0



Features:


1. High refresh rate, >3840HZ, which let the picture is vivider


2. All led panels have high strength corner protectors. Protect leds from damage during transportation and installation.


3. Convenient maintainance --- module front & rear service


4. Independent power supply box without wire


5. Support curve connection --- ±2.5°&5° concave & converse connection


Specifications:



Item Parameter
Module specifications Mode P2.604 P2.97 P3.91 P3.91
Module size 250*250 250*250 250*250 250*250
Module pixel 96*96 84*84 64*64 64*64
Scan 1/32 1/28 1/16 1/16
Pixel configuration 1R1G1B 1R1G1B 1R1G1B 1R1G1B
LED SMD1515 SMD1515 SMD2121 SMD2121
Max power consumption (W/piece) 40W 40W 40W 40W
Mask Have Have Have Have
Main Specifications Cabinet size 500*500 500*500 500*500 500*1000
Cabinet pixel 192*192 168*168 128*128 128*256
Density (dot/m2) 147456 112896 65536 65536
Brightness(cd/m2) 500-1000 500-1000 500-1000 500-1000
Max power consumption (W/piece) 160W 160W 160W 320W
Avg power consumption (W/piece) 50W 50W 50W 100W
Cabinet weight(KG) 7.5KG 7.5KG 7.5KG 13.6KG
Cabinet material Die-cast aluminum
IP grade IP45 IP45 IP45 IP45
Gray level 16 bit 16 bit 16 bit 16 bit
Fresh rate 3840HZ 3840HZ 3840HZ 3840HZ
Best viewing distance 3M 3M 4M 4M
Power(V) AC110-220V
Working temperature -20℃-50℃



SMD1515 Stage LED Video Wall 4

SMD1515 Stage LED Video Wall 5



After Sales Service:


1. Telephone investigation: Our after-sales team will phone the user every month during the warranty period to follow up the working condition of the products, and to discover and solve problems, if necessary.



2. Free guarantee repair (including labor and material); free repair service during the quality warranty period and reasonable charge for spare parts and maintaining service after the quality warranty period. We will never exempt our responsibilities on product owned defects.



3. Responding time: Upon receiving user’s notification, we ensure 24-hour after-sales technical support.



4. Spare parts: Necessary spare parts are provided together with products to customers.



5. Free technical training: Integrative and normative technology training is available for free to customers by our technical personnel to ensure they are skilled in regular operations of hardware and software of products and they are able to estimate and solve small problems.



6. Software upgrade: Lifelong maintenance of controlling system, incessant improvement of the system functions and continuous software upgrades.
