Product Details:

Place of Origin: Guangdong, China
Brand Name: EliteLED
Certification: CE, CCC
Model Number: P4 P5 P8 P10

Payment & Shipping Terms:

Minimum Order Quantity: 1sqm
Price: Negotiable
Packaging Details: Wooden cases or flight cases
Delivery Time: 18 days
Supply Ability: 3000sqm/month
Get Best Price Contact Now

Detail Information

Application: Outdoor Advertising Pixel Pitch: 2-10mm
Brightness: 5000-8000nits Product Name: P8 Outdoor Led Panel
Cabinet Size: Customized LED Chip: Nationstar, Kinglight
Control System: Nova Certificate: CE ROHS
Warranty: 2 Years
High Light:

Meanwell Power Outdoor Advertising Billboard

,

EMC Outdoor Advertising Billboard

,

EMC Outdoor Smd Led Screen

Product Description

High Brightness Meanwell Power Outdoor Fixed LED Display SMD Advertising Screen​



Specifictions:



1. Low power consumption, low heat, energy saving and environmental protection.



2. Uniform color, high contrast, the picture is beautiful and natural.



3. Short leading time for fast delivery.



4. Certification: EMC, FCC, IP65



5.. Patent mask design, dust-proof and waterproof, protection level up to IP65.





LED Screen Information View Distance In/meter 392/10
View Angle (H/V) Deg. 140/140
LED Type N/A SMD3535
Pixel Pitch Unit 10
Brightness Nits 6500
Module Dimension(WxH)
In/mm 12.6x6.3/320x160
Module Pixel(WxH)
Pixel 32x16
Cabinet Dimension(WxH)
In/mm 37.8x37.8/960x960
Cabinet Pixel(WxH)
Pixel 96x96
Cabinet Weight
Kg 50
Cabinet Material
N/A Steel
Maintenance Way
N/A Rear
Power Operating AC Operation V AC100~240V 50-6-Hz switchable
Power Consumption(Max./Ave.) W/m2 730/220
Control System
Refresh Rate
Hz 1920
Driving Type
Scan 1/2
Digital Processing
Bit 14
Gray Scale
Level 16384
Support Input
N/A Composite video,S-video,DVI,HDMI,SDI,HD-SDI
Control Distance
Meter Ethernet cable within 100 meters, Optical fiber within 5KM
Raliability Ingress Protection N/A IP65 front/IP54 back
Operating Humidity RH 10~95%
Operating Tem. F/C -4F~140F/-30~60
Life Time(50% brightness) Hour 100,000



Meanwell Power Outdoor Advertising Billboard Smd Led Screen EMC FCC Certified 0



Meanwell Power Outdoor Advertising Billboard Smd Led Screen EMC FCC Certified 1



Meanwell Power Outdoor Advertising Billboard Smd Led Screen EMC FCC Certified 2

About Us:



EliteLED is a professional manufacturer of LED Video walls ,outdoor indoor LED Display Screen, LED Panel in Shenzhen, China with led display exported to more than 100 countries and regions, passed CE,ROHS FC Certifications. If you are considering LED go with the known leader of LED display suppliers, you are welcome to contact us, we will not let you down.



Product Features:



1. Wide application field & short ROI time:
commercial advertising LED display screen, Stadium perimeter LED display screen, Mobile trailer LED display screen for mobile media, shopping mall LED display screen for logo showing, bank&stock exchange LED display screen for rates showing, train & bus station LED display screen, air port LED display screen, telecommunication LED display screen system for information showing and instruction

2. High Contrast ratio: 4000:1
Which is a very high level to ensure a vivid image of our LED display screen system.

3. Clear vivid image quality:
Even in direct, full-on sunlight to ensure you attract more audience to get short ROI of your LED display screen's investment.

4. Long-term Brightness:
7000-nit brightness (for outdoor full color)(2000 nits brightness for indoor full color ) capacity throughout product lifetime of the LED display screen.

5. Easy Installation & Using:
easy & simple installation interface and user friendly software to ensure the user friendly interface of the LED display screen system

6. Convenient Servicing:
Front and rear cabinet access makes the maintenance work very convenient and low cost to help you concentrate more time and energy on your main marketing promotion business.
