Corner Seamless 90 Degree Led Screen 10mm Led Display Energy Saving
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | EliteLED |
| Certification: | CE |
| Model Number: | Outdoor p8 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1sqm |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Wooden cases or flight cases |
| Delivery Time: | 18 days |
| Supply Ability: | 3000sqm/month |
|
Detail Information |
|||
| Application: | Outdoor Advertising | Pixel Pitch: | 10mm |
|---|---|---|---|
| Brightness: | 7000nits | Product Name: | P10 Outdoor Led Panel |
| Cabinet Size: | 1000x1000mm | LED Chip: | Nationstar |
| Control System: | Nova | Certificate: | CE ROHS |
| Warranty: | 2 Years | ||
| High Light: | Corner Seamless 90 Degree Led Screen,90 Degree Led Screen 10mm,Corner Seamless 10mm Led Display |
||
Product Description
Corner 90 Degree Seamless Outdoor Fixed Led Display With Energy Saving Design
Specifictions:
1. Front access, slim aluminum cabinet, easy and fast to install and maintenance.
2. 2.8V&3.8V energy saving design, no need air-conditioner, environmental and save cost.
3. Support 90 degree installation, seamless splicing at the corner.
4. Totally warterproof of front and back, IP67 and IP65
5. Competitive price, you are welcome to contact us for a free project evaluation.
| Model No. | P10.41 | P7.8 | P6.25 | P5.2 | P4.8 | P3.9 |
| Pixel pitch | 10.4mm | 7.82mm | 6.25mm | 5.2mm | 4.81mm | 3.91mm |
| Pixel density (dots/m2) |
9246 | 16352 | 25600 | 36982 | 43264 | 65536 |
| LED encapsulation | SMD2727 | SMD2727 | SMD2727 | SMD2727 | SMD1921 | SMD1921 |
| Scan rate | 1/2 scan | 1/4 scan | 1/5 scan | 1/6 scan | 1/7 scan | 1/8 scan |
| Module size | 500 x 250 mm | |||||
| Module Resolution | 48 x 24 | 64 x 32 | 80 x 40 | 96 x 48 | 104 x 52 | 128 x 64 |
| Cabinet size | 1000 x 1000 x 73mm (Optional) | |||||
| Cabinet Resolution | 96 x 96 | 128 x 128 | 160 x 160 | 192 x 192 | 208 x 208 | 256 x 256 |
| Weight per Cabinet | 24.5 kg | |||||
| Brightness | ≥6500/ 10000nits |
≥6000/ 10000nits |
≥6000/ 10000nits |
≥5500/ 10000nits |
≥5000/ 10000nits |
≥5000/ 10000nits |
| Max.power consumption | 500W | 500W | 500W | 550W | 800W | 800W |
| Ave.power consumption | 175W | 175W | 175W | 185W | 270W | 270W |
| Energy Saving design | 2.8V & 3.8V Low voltage | 4.6V / 5V voltage | ||||
| Protection Degree | Front IP67/Rear IP65 | |||||
| Service | Front & Rear Dual service | |||||
| Power Supply | AC120 /240V (50Hz) (optional) | |||||
| Refresh Rate | ≥ 1920Hz(3840Hz Optional) | |||||
