320x160mm P1.86 Fine Pitch LED Display 4K LED Video Wall  For Meeting Room

320x160mm P1.86 Fine Pitch LED Display 4K LED Video Wall For Meeting Room

Product Details:

Place of Origin: Guangdong, China
Brand Name: EliteLED
Certification: CE
Model Number: P1.86

Payment & Shipping Terms:

Minimum Order Quantity: 1sqm
Price: Negotiable
Packaging Details: Wooden cases or flight cases
Delivery Time: 18 days
Supply Ability: 3000sqm/month
Get Best Price Contact Now

Detail Information

Application: Indoor Pixel Pitch: P1.86
Brightness: 800nits Product Name: 4K Led Video Wall
Cabinet Size: 640x480mm Module Size: 320x160mm
LED Chip: Kinglight Control System: Nova
Certificate: CE ROHS Warranty: 2 Years
High Light:

P1.86 Fine Pitch LED Display

,

P1.86 4K LED Video Wall

,

320x160mm Fine Pitch LED Display

Product Description

4K Indoor LED Video Wall P1.86 UHD Led Screen For Meeting Room TV Station



Features:


1. 320*160mm module size design, compatible with 640*480mm die cast aluminum cabinet, compatible with P1.25/P1.538/P1.667/P1.86/P2/P2.5, etc



2. Select high-performance PCB board substrate and cooperate with rigorous process to greatly reduce the color temperature phenomenon



3. Die cast aluminum cabinet structure, ultra-light and ultra-thin, with a weight of 6Kg and a thickness of 50mm


4. Unit cabinet seamless splicing, more convenient for assembly and transportation



5. Wireless connecting between module and board, front maintenance design, easy installation and cost saving



6. High precision, the cabinet is CNC processed



7. Reliable, high strength and good heat dissipation



8. Front access, cabinet and module are magnetic, easy maintenance



Pixel Pitch(mm) 1.538 1.667 1.86 2 2.5 3.076
Pixel Matrix Per Sq.m 422,500 360,000 288,888 250,000 160,000 105,625
Pixel Configuration SMD1212 SMD1515 SMD2121
Brightness (nits) 800 800 800 1000 1000 1000
Scan 1/52 1/48 1/43 1/40 1/32 1/24
Cabinet Resolution 416x312 384x288 344x258 320x240 256X192 208X156
Power Con. (Max / Avg) 500/150 w/sqm
Module Dimension 320x160mm
Cabinet Weight 6kg ( Die-casting Aluminum)
Cabinet Dimension 640x480mm
Service Access Full Front
Refresh Rate (HZ) ≥3840
Grey Scale (bit) 16
Viewing Angle (H/V) 160 / 160
IP Rate IP41
Input Voltage (AC) 110V / 240V



320x160mm P1.86 Fine Pitch LED Display 4K LED Video Wall  For Meeting Room 0
